Customized High Transmittance ITO Conductive Glass 10~15 Ohms 300*300*1.1mm for Display Touchscreen
Customized High Transmittance ITO Conductive Glass | 10~15 Ω/sq | 300×300×1.1mm for Display & Touchscreen
Precision Engineered for Touchscreen, OLED & High‑End Display Applications
Our customized high transmittance ITO (Indium Tin Oxide) conductive glass delivers exceptional optical clarity and uniform low resistivity. With a sheet resistance of 10–15 ohms per square, dimensions of 300×300×1.1mm, and full customization options, it is the ideal substrate for capacitive touchscreens, OLED lighting, smart windows, and advanced display R&D.
Why Choose This ITO Conductive Glass?
1. High Transmittance + Low Resistivity – No Trade‑off
Most ITO glasses sacrifice optical clarity for lower resistance. Our sputtering process achieves >86% transmittance at 550nm while maintaining a tight 10–15 Ω/sq range – critical for responsive touchscreens and bright displays.
2. Precision 300×300×1.1mm Substrate
-
Size: 300mm × 300mm (±0.2mm)
-
Thickness: 1.1mm (±0.05mm)
-
Edge: Fine ground or polished (customizable)
-
Flatness: <0.1% per 100mm
3. Fully Customized – Your Design, Our Glass
We offer tailor‑made solutions:
-
Size: From 10×10mm to 500×500mm (or cut to your drawing)
-
Resistivity: 5 Ω/sq, 15 Ω/sq, 30 Ω/sq, 100 Ω/sq, etc.
-
ITO coating on one or both sides
-
Patterned ITO (etching service available)
-
Additional layers: SiO₂ barrier, anti‑glare, anti‑fingerprint
4. Rigorous Quality Control
Every batch is tested for:
-
Sheet resistance (4‑point probe)
-
Transmittance (UV‑Vis spectrophotometer)
-
Surface uniformity (map scanning)
-
Adhesion & environmental stability (tape test, 85/85 humidity)
Technical Specifications
| Substrate | Soda‑lime glass or borosilicate (custom) |
| ITO thickness | 120–180 nm (adjustable for target resistivity) |
| Sheet resistance | 10 – 15 Ω/sq (custom: 5 – 500 Ω/sq) |
| Transmittance (550nm) | ≥86% (with anti‑reflection coating optional) |
| Haze | <0.5% |
| Substrate size | 300 × 300 mm (±0.2 mm) |
| Thickness | 1.1 mm (±0.05 mm) |
| Operating temp. | –40°C to +300°C (depending on glass type) |
| Surface roughness | <1.0 nm Ra (polished side) |
| ITO side | Typically one side; double‑sided available |
Frequently Asked Questions
Q: Can I get a sample before bulk order?
A: Yes, samples (≤10 pcs) are available. Lead time: 5–7 working days.
Q: How does 10–15 Ω/sq compare to standard ITO glass?
A: Typical ITO glass is 100–300 Ω/sq. 10–15 Ω/sq is ultra‑low resistivity, ideal for high‑speed touch sensing and large‑area displays.
Q: Is the glass chemically strengthened?
A: Standard is non‑strengthened. We can provide chemically strengthened (ion‑exchange) glass upon request – please specify.
Q: What is the maximum size you can coat?
A: Up to 550×650 mm. Larger sizes available for specialized orders.
Q: Do you provide cutting, drilling, or edge grinding?
A: Yes. All secondary processing is done in‑house.
Q: How should I store the ITO glass?
A: Store in a dry, dust‑free environment (RH <40%). Avoid direct handling of the coated surface.
Company Introduction
Founded in 2012, Fuxin Glass is a leading manufacturer specializing in the research, development, production, and export of cover glass, headquartered in Dongguan, China, near the ports of Shenzhen and Guangzhou.
With 13 years of industry experience, Fuxin serves customers in over 80 countries worldwide. With ISO/RoHS/JIS Z certifications, Fuxin Glass is dedicated to providing high-quality glass solutions for electronic displays and smart devices. Its products are widely used in interactive display, automotive electronics, industrial equipment, medical devices, home appliances, and smart devices. The products feature high light transmittance (over 95%), high hardness (Mohs 6), and excellent scratch and impact resistance. The 21,000-square-meter factory is equipped with four fully automated production lines, with a monthly production capacity of 300,000 pcs. We support small-batch trial production and large-scale delivery, and provide one-step technical support and after-sales service. Multi-dimensional customization is supported as well: including but not limited to mold design (samples can be produced in as fast as 7 days), special optical processing (AR/AF/AG/AM combination), explosion-proof structure design (multi-layer composite structure), color customization (7 colors are optional), silk screen logo, etc., to meet the personalized needs of customers. Our products have successfully entered mainstream markets such as North America, Japan, South Korea, India, and Europe, and widely serve interactive ( such us all in one machine, IFPD, smart white board ), automotive central control screens, industrial HMI, smart home panels and other fields.
We always adhere to the principle of "integrity, quality and win-win" and are willing to establish good long-term cooperative relationships with customers all over the world!
Partial Sample Display
Factory Overview
Inspection Progress
Certification
Package
Delivery & Lead Time
| Original Country | China |
| FOB Port | Shenzhen or Hongkong |
| HS Code | 700719000 |
| Lead Time | Sample within 7 days, bulk order 15~20 days |
| Delivery | By sea / DHL / Fedex / UPS |
Payment Details
1. Soda-lime Glass (Ordinary Flat Glass)
- Composition: Mainly composed of silicon dioxide (SiO₂, approximately 70%), sodium oxide (Na₂O), and calcium oxide (CaO).
- Characteristics: Easy to produce, low cost, but poor thermal stability and brittle.
- Applications: The most common type of glass, used for doors, windows, bottles, jars, and everyday utensils.
2. Borosilicate Glass (Heat-Resistant Glass)
- Composition: Based on soda-lime glass, boron oxide (B₂O₃) is added.
- Characteristics: Low coefficient of thermal expansion, high temperature resistance, resistance to rapid temperature changes (not easily cracked by sudden heating and cooling), good chemical stability.
- Applications: Laboratory instruments (such as beakers and test tubes), heat-resistant tableware (such as baking pans and glass pots), high-end flashlight lenses, etc. Well-known brands include Pyrex.
3. Aluminosilicate Glass
- Composition: Contains a large amount of aluminum oxide (Al₂O₃) and silicon dioxide (SiO₂).
- Characteristics: High hardness, scratch resistance, high mechanical strength, superior performance compared to borosilicate glass.
- Applications: Cover glass for high-end mobile phones/tablets, aviation glass, etc. Well-known brands include Corning Gorilla Glass.
4. Quartz Glass
- Composition: Silicon dioxide (SiO₂) content is above 99%.
- Characteristics: Excellent heat resistance (softening point up to 1700℃), wide light transmission spectrum (from ultraviolet to infrared), high purity, and excellent chemical stability. However, it is expensive.
- Applications: Semiconductor industry, optical devices, observation windows in high-temperature furnaces, ultraviolet lamps, etc.
- Product dimensions & glass thickness
- Application / usage
- Edge grinding type
- Surface treatment (coating-AG/AR/AF/AM or overlay, printing, etc.)
- Packaging requirements
- Quantity or annual usage
- Required delivery time
- Drilling or special hole requirements
- Drawings or photos
-
